Female Threaded Double Elbow
- Hydrodynamic Twin-Bend Design: Engineered with synchronized internal radii to smoothly deflect dual fluid paths at 90-degree vectors, reducing boundary-layer separation and minimizing systemic velocity loss.
- Integrated Solid Forged Geometry: Molded through high-tonnage multi-directional forging to secure a completely homogenous grain flow structure, preventing mechanical fatigue under continuous cyclical pressure spikes.
- High-Fidelity Thread Calibration: Features multi-axis CNC machined internal female threads that ensure strict alignment profiles and total tightness matching for complex manifold configurations.
The industrial female threaded double elbow fitting array by Xuan Yang International delivers exceptional pressure containment and balanced fluid distribution for high-density plant setups, heavy HVAC cooling systems, and chemical processing networks. Spanning an extensive size matrix from 20mm up to 63mm (1/2" to 2"), these double-deflection components eliminate the need for complicated assemblies built from separate fittings, reducing leak points and space requirements. Tested under strict pneumatic and hydrostatic benchmarks, this structural coupling guarantees long-term durability in high-vibration piping environments.
Request A Free QuoteTechnical Datasheet & Dimensional Specifications
| Specification Parameters | Engineering & Manufacturing Standards |
|---|---|
| Metric Size Options | 20mm, 25mm, 32mm, 40mm, 50mm, 63mm Nominal Outer Diameters |
| Imperial Thread Mapping | 1/2", 3/4", 1", 1-1/4", 1-1/2", 2" Female Parallel / Tapered Ports |
| Primary Material Options | Brass / SUS304 / SUS316 Stainless Steel Core |
| Thread Conformance Standards | ISO 228-1 Parallel (G) or ASME B1.20.1 (NPT) Custom Specifications |
| Hydrostatic Pressure Rating | PN16 / PN25 High-Pressure System Configurations Compliant |
| Internal Radii Finish | Smooth Core Cast / Burnished Finish for Low Fluid Resistance |
| System Applications | Parallel Fluid Distribution, Manifold Headers, Chilled Water Loops |
